The YW-AZ series automatic roll-to-roll embossing machine integrates mechanical, electrical, pneumatic and hydraulic systems. It embosses various paper and plastic film rolls to create diverse decorative patterns.
Equipped with automatic hydraulic lifting, auto heating and cooling control, frequency conversion speed regulation, automatic tension control and automatic oil pressure control functions.
Products Description
Products Feature
1. Manual mode available for machine testing, residual paper running and wool fiber roller cleaning.
2. Embossing pattern roller and wool fiber roller are precisely matched to achieve even line pressure for stable embossing results.
3. Equipped with photoelectric paper break sensors and maximum roll diameter protection. The machine stops automatically and shows on-screen alerts when paper breaks or the roll reaches the max diameter.
4.Supports single-sided and double-sided embossing. Embossing pattern roller can be replaced conveniently to produce different patterns.
Main Parameter
|
Model |
YW-920Z |
| Maximum embossing width | 889mm |
| Applicable paper weight | 105-500 g/m2 |
| Maximum embossing speed | 60 m/min |
| Maximum rewinding roll diameter | 1300 mm |
| Embossing pressure | 0.2 -1 MPa (2-10 kg/cm2) |
| Embossing temperature | ≤100 ℃ |
| Machine noise | ≤80 dB |
| Working environment temperatur | 5-40 ℃ |
| Working environment humidity | 20%～80%RH |
| Power voltage | 3 phases 380V 50/60Hz |
| Total power | 22 kw |
| Dimension | 4660 x 2000 mm |
| Weight | 4200 kg |
Application
Company Proflie
Installation
The above price not contain the installation and training charge, if customers request our engineer for this service, customers should pay the flight tickets, hotel, food and daily wage.
Guarantee
One year, within one year, the damaged spares by nature can be changed for free.
