Ruian Koten Machinery Co., Ltd. is one of the leading manufacturers and suppliers of Automatic Roll To Roll Hydraulic Embossing Machine in China. With abundant experience, we ware committed to providing high quality machinery made in China with competitive price. If you're going to buy CE approved Automatic Roll To Roll Hydraulic Embossing Machine, welcome to get quotation from our factory.
The YW-920A-Z automatic embossing machine delivers superior performance for roll-to-roll embossing processing. It is dedicated surface finishing equipment for materials including plain paper, coated paper, composite paper and greeting cards. It can also process aluminum-plastic composite materials, leather and other substrates under specified working conditions.
Embossing creates concave-convex textures on materials with a strong 3D visual effect. This machine broadens the application range of printing and packaging machinery to satisfy development demands of the modern printing & packaging industry.
Products Description
Products Feature
1. Manual mode available for machine testing, residual paper running and wool fiber roller cleaning.
2. Embossing pattern roller and wool fiber roller are precisely matched to achieve even line pressure for stable embossing results.
3. Equipped with photoelectric paper break sensors and maximum roll diameter protection. The machine stops automatically and shows on-screen alerts when paper breaks or the roll reaches the max diameter.
4.Supports single-sided and double-sided embossing. Embossing pattern roller can be replaced conveniently to produce different patterns.
Main Parameter
|
Model |
YW-920Z |
| Maximum embossing width | 889mm |
| Applicable paper weight | 105-500 g/m2 |
| Maximum embossing speed | 60 m/min |
| Maximum rewinding roll diameter | 1300 mm |
| Embossing pressure | 0.2 -1 MPa (2-10 kg/cm2) |
| Embossing temperature | ≤100 ℃ |
| Machine noise | ≤80 dB |
| Working environment temperatur | 5-40 ℃ |
| Working environment humidity | 20%～80%RH |
| Power voltage | 3 phases 380V 50/60Hz |
| Total power | 22 kw |
| Dimension | 4660 x 2000 mm |
| Weight | 4200 kg |
Application
Company Proflie
Installation
The above price not contain the installation and training charge, if customers request our engineer for this service, customers should pay the flight tickets, hotel, food and daily wage.
Guarantee
One year, within one year, the damaged spares by nature can be changed for free.
