Ruian Koten Machinery Co., Ltd. is one of the leading manufacturers and suppliers of automatic rigid box making machine in China. With abundant experience, we ware committed to providing high quality machinery made in China with competitive price. If you're going to buy CE approved automatic rigid box making machine, welcome to get quotation from our factory.
Products Description
The S350YZ (single wrapping station) and S350YSZ (dual wrapping stations) are compact‑size fully‑automatic rigid box‑making machines. Designed for high‑precision production of premium boutique rigid boxes, they serve packaging demands for consumer electronics, jewelry, cosmetics and luxury gifts.
Equipped with Yamaha manipulator together with dual‑camera visual positioning system, the machines deliver outstanding positioning accuracy up to ±0.1 mm (S350YZ). Servo‑driven feeding, automatic glue‑viscosity control and IoT remote‑support functions guarantee stable high‑volume production. The dual‑station S350YSZ boosts output up to 40 pcs/min for higher‑capacity requirements.
Products Feature
- Servo‑controlled rear‑suction facial‑paper feeder: Advanced servo‑driven feeding with rear‑suction push‑forward design effectively prevents double‑sheet feeding and ensures stable running. Parameters for each station can be freely adjusted to fit various box specifications.
- Automatic glue viscosity control: Monitors and stabilizes glue viscosity continuously, eliminating glue inconsistency and securing consistent finished‑box quality.
- High‑precision visual positioning system: Dual 500W industrial cameras cooperate with YAMAHA SCARA manipulator. Motorized camera adjustment with self‑locking roller‑screw structure avoids camera position shift during operation, achieving precise alignment with ±0.1 mm positioning accuracy (S350YZ).
- Electronic‑cam full‑machine servo control: Enables highly‑coordinated mechanical movements and one‑key speed adjustment for quick commissioning and flexible production change‑over.
- Integrated whole‑box bubble‑press structure: Completes full‑box pressing and bubble removal inline. Finished boxes require no secondary foaming process.
- Absolute double‑cylinder box positioning device: Mechanical double‑cylinder positioning keeps every box in uniform position, avoiding positioning errors caused by belt friction.
Main Paramater
|
MODEL |
S350YZ |
S 350YSZ |
|
Paper Size(AxB) |
Min. 80x80 mm Max. 120x500 mm |
|
|
Paper thickness |
80-250g/㎡ |
|
|
Carton size |
Min. C110mm D140mm H10mm W50mm L50mm Max. C600mm D900mm H100mm W250mm L350mm |
|
|
Cardboard thickness |
0.8-3mm |
0.8-3mm |
|
Folding size |
Rmin:15mm Rmax:75mm |
Rmin:15mm Rmax:75mm |
|
Folding ear size |
15mm-80mm |
15mm-80mm |
|
Manipulator model |
YK600XG-200 |
YK600XG-200 |
|
Position precision |
≤ ± 0.1 mm |
≤ ± 0.2 mm |
|
Production speed |
0-30 pcs/min |
0-40 pcs/min |
|
Stacking height of tissue paper |
480 mm |
480 mm |
|
Stacking height of cardboard |
1000 mm |
1000 mm |
|
Gas source requirements |
45 L/min 0.8 Mpa |
50 L/min 0.8 Mpa |
|
Total power of equipment |
17KW AC380V |
29KW AC380V |
|
Equipment size |
6800x3800x3200 mm |
6800x4700x3200 mm |
Application
Ideal for mass‑manufacturing small‑to‑medium‑size high‑end rigid boxes:
‑ Consumer‑electronics packaging boxes
‑ Jewelry & watch gift boxes
‑ Cosmetic & beauty‑product packaging
‑ Premium gift boxes and luxury boutique packaging
Company Proflie
Installation
The above price not contain the installation and training charge, if customers request our engineer for this service, customers should pay the flight tickets, hotel, food and daily wage.
Guarantee
One year, within one year, the damaged spares by nature can be changed for free.
