Ruian Koten Machinery Co., Ltd. is one of the leading manufacturers and suppliers of automatic collapsible box side wings making machine in China. With abundant experience, we ware committed to providing high quality machinery made in China with competitive price. If you're going to buy CE approved automatic collapsible box side wings making machine, welcome to get quotation from our factory.
Products Description
QZD‑600S automatic collapsible box side‑wall forming machine is specially developed to solve the pain points of traditional rigid boxes, such as large bulk volume, high freight cost and easy damage caused by extrusion during transport.
Equipped with servo drive, photoelectric positioning, servo correction and servo hemming technology, this machine fully automates the whole workflow including face‑paper feeding, gluing, cardboard feeding, positioning, edge trimming and folding forming. It produces high‑quality collapsible rigid boxes which can be shipped flat. This greatly cuts logistics expenses and saves warehouse storage space, bringing remarkable economic benefits for packaging manufacturers. The complete production line only requires 1‑2 operators, achieving high‑speed output up to 35 pieces per minute with positioning accuracy within ±0.25 mm.
Products Feature
- Full‑automatic Servo Control: PLC touch‑screen operated servo system, integrating photoelectric positioning, servo correction and servo hemming for stable and precise running.
- Complete One‑pass Processing: Automatically completes paper feeding, gluing, cardboard positioning and four‑side folding to make flat‑pack collapsible boxes.
- Great Labor Reduction: The whole production line only needs 1‑2 operators, significantly lowering labor costs.
- High Speed & High Precision: Max working speed reaches 35 pcs/min, positioning accuracy ≤ ±0.25 mm for premium‑grade collapsible gift boxes.
- Logistics & Storage Optimization: Produces flat collapsible boxes to reduce bulk volume, minimize transportation cost and save warehouse space.
- Overseas Support Available: Our engineers are available for on‑site installation and training upon the customer's request.
Main Paramater
|
Model |
QZD-600S |
|
Length of paper |
190-1030 mm |
|
Width of paper |
100-460 mm |
|
Thickness of paper |
80-200 g/m² |
|
Thickness of board |
1-3 mm |
|
Thickness of cardboard |
0.5-3 mm |
|
Length of finished product |
150-800 mm |
|
Finished product width |
40-200 mm |
|
Position precision |
≤±0.25 mm |
|
Speed |
0-35 pcs/min |
|
Weight |
4000 kg |
|
Dimension |
8700x2600x1750 mm |
Application
This machine is designed for mass‑production of high‑end collapsible rigid boxes for the packaging industry:
‑ Luxury gift boxes, cosmetic boxes, jewelry boxes and premium retail packaging
‑ Flat‑pack collapsible rigid boxes that can be folded flat for shipment and storage
‑ Suitable for rigid‑box factories, printing & post‑press plants and packaging enterprises focusing on high‑grade box orders
It handles face paper of 80‑200 g/m² and cardboard thickness from 0.5‑3 mm, covering a wide range of finished collapsible box dimensions.
Company Proflie
Installation
The above price not contain the installation and training charge, if customers request our engineer for this service, customers should pay the flight tickets, hotel, food and daily wage.
Guarantee
One year, within one year, the damaged spares by nature can be changed for free.
